ZENIT® W300
Equipped with a total of twenty-one 15 W RGBW LEDs for a huge 10,000 lm output, the Cameo ZENIT® W300 is a powerful IP65 rated wash light for demanding outdoor applications. In addition to RDM and standard DMX capability it boasts a built-in 2.4 GHz W-DMX™ transceiver by Wireless Solution Sweden AB for convenient wireless control. The fixture also provides a rich variety of stunning automated programs for standalone or wireless master-and-slave operation.
For maximum versatility, the ZENIT® W300 sports Cameo's innovative SnapMag® technology. It allows you to add filter frames in less than a second without the need for tools or dismantling. Magnetic SnapMag® frames with precision light shaping diffusers and a 4-way barn door are available as dedicated accessories.
Featuring advanced 16-bit technology for high-resolution colour mixing and dimming and an 21° beam spread, the ZENIT® W300 projects highly intense, uniform washes. With colour temperature correction, selectable dimming curves and dimming response, the fixture is the perfect tool for truly professional lighting.
The ZENIT® W300's die cast aluminium housing integrates temperature controlled fans that ensure optimized, low noise operation while a bright OLED display with four touch buttons permits easy, intuitive configuration. The fixture comes with an IR remote control, omega mounting bracket and power cord.
Product type | LED Outdoor Wash Light |
Type | ZENIT |
Colour spectrum | RGBW |
Number of LEDs | 21 |
LED type | 15 W |
Average LED lifetime | 50000 |
Refresh rate | Adjustable: 800, 1200, 2000, 3600, 12000, 25000 Hz |
Dispersion | 21 ° Beam, 40 ° Field (without Diffusor) ° |
Lens | PE and tempered glass |
DMX input | 5-pin IP65 |
DMX output | 5-pin IP65 |
DMX mode | 10-channel, 15-channel, 2-channel, 3-channel, 4-channel, 8-1 Channel, 8-2 Channel |
DMX Functions | Auto programs, colour macro, CTC (Colour Temperature Correction), Dimmer, Dimmer Curve, Dimmer Fine, Dimmer Response, RGBW, RGBW Fine, strobe |
Standalone modes | Auto programs, colour macro, Device Settings, Master / Slave mode, Static, system info, Tunable White, User Colours |
Controls | Enter, Mode, Value Down, Value Up |
Indicators | OLED Display |
Operating voltage | 100 V AC - 240 V AC, 50 - 60 Hz |
Power consumption | 300 W |
power factor | 0.99 PF (120V) / 0.96 PF (230V) |
Power connector | IP65 |
Power supply connection | IP65 |
Housing material | Aluminium |
Cabinet colour | Black |
Protection class IP | IP65 |
Cooling | IP65 temperature-controlled fans |
Luminous flux | 10661 lm |
Efficiency | 35.3 lm/W |
Operating Temperature | -15 - 45 °C |
Other features | ETL certified |
Width | 377 mm |
Length | 256 mm |
Height | 140 mm |
Weight | 8 kg |
