ZENIT® W300
Equipped with a total of twenty-one 15 W RGBW LEDs for a huge 10,000 lm output, the Cameo ZENIT® W300 is a powerful IP65 rated wash light for demanding outdoor applications. In addition to RDM and standard DMX capability it boasts a built-in 2.4 GHz W-DMX™ transceiver by Wireless Solution Sweden AB for convenient wireless control. The fixture also provides a rich variety of stunning automated programs for standalone or wireless master-and-slave operation.
For maximum versatility, the ZENIT® W300 sports Cameo's innovative SnapMag® technology. It allows you to add filter frames in less than a second without the need for tools or dismantling. Magnetic SnapMag® frames with precision light shaping diffusers and a 4-way barn door are available as dedicated accessories.
Featuring advanced 16-bit technology for high-resolution colour mixing and dimming and an 21° beam spread, the ZENIT® W300 projects highly intense, uniform washes. With colour temperature correction, selectable dimming curves and dimming response, the fixture is the perfect tool for truly professional lighting.
The ZENIT® W300's die cast aluminium housing integrates temperature controlled fans that ensure optimized, low noise operation while a bright OLED display with four touch buttons permits easy, intuitive configuration. The fixture comes with an IR remote control, omega mounting bracket and power cord.
DMX512
Communication standard DMX512 was developed specially for lighting systems in 1986. Up to 32 DMX devices can be daisy-chained and controlled via a control source (e.g. a light mixer).
Environment-friendly
The high energy efficiency, the long service life of the LED lamps and the low level of heat dissipation make this device particularly environment-friendly.
Protection class IP65
The IP code of the protection class indicates how well the sensitive parts of the device are protected from foreign bodies and water entering. This device is fully protected from the penetration of dust and water jets.
Infrared remote control
The device is fitted with an infrared sensor and can be controlled wirelessly using the IR remote control unit included.
LED technology
LEDs are ideal for use in lighting systems: They are bright and have a low level of heat dissipation, a long operating life and low energy consumption. Moreover, LED systems often weigh less than conventional lighting systems.
Master & slave
Master/slave operation allows identical DMX devices to be controlled by a DMX device of the same model and software standard. All the devices are connected by DMX cables in series. The master device is then set to run in standalone mode and the slave devices are set to run in slave mode.
RGB additive colour system plus white LEDs
Additional white LEDs create more contrast and clearer colour boundaries. What is more, they improve the creation of white and pastel colours.
Standalone mode
In standalone mode, the device functions are controlled via integrated programmes, so no light mixer or “master” controller is required.
RDM
This device has full RDM capability. The RDM protocol supplements the DMX protocol and enables bidirectional communication via a standard DMX network. It simplifies configuration, administration and monitoring of RDM devices connected to an RDM controller.
The W-DMX™ feature facilitates the wireless transmission of DMX control data.
Various dispersion angles possible
SnapMag™ technology allows objects to be simply and quickly magnetically fixed to a device.
The device features wireless master/slave operation.
This product is ETL certified.
| Product type | LED Outdoor Wash Light |
| Type | ZENIT |
| Colour spectrum | RGBW |
| Number of LEDs | 21 |
| LED type | 15 W |
| Average LED lifetime | 50000 |
| Refresh rate | Adjustable: 800, 1200, 2000, 3600, 12000, 25000 Hz |
| Dispersion | 21 ° Beam, 40 ° Field (without Diffusor) ° |
| Lens | PE and tempered glass |
| DMX input | 5-pin IP65 |
| DMX output | 5-pin IP65 |
| DMX mode | 10-channel, 15-channel, 2-channel, 3-channel, 4-channel, 8-1 Channel, 8-2 Channel |
| DMX Functions | Auto programs, colour macro, CTC (Colour Temperature Correction), Dimmer, Dimmer Curve, Dimmer Fine, Dimmer Response, RGBW, RGBW Fine, strobe |
| Standalone modes | Auto programs, colour macro, Device Settings, Master / Slave mode, Static, system info, Tunable White, User Colours |
| Controls | Enter, Mode, Value Down, Value Up |
| Indicators | OLED Display |
| Operating voltage | 100 V AC - 240 V AC, 50 - 60 Hz |
| Power consumption | 300 W |
| power factor | 0.99 PF (120V) / 0.96 PF (230V) |
| Power connector | IP65 |
| Power supply connection | IP65 |
| Housing material | Aluminium |
| Cabinet colour | Black |
| Protection class IP | IP65 |
| Cooling | IP65 temperature-controlled fans |
| Luminous flux | 10661 lm |
| Efficiency | 35.3 lm/W |
| Operating Temperature | -15 - 45 °C |
| Other features | ETL certified |
| Width | 377 mm |
| Length | 256 mm |
| Height | 140 mm |
| Weight | 8 kg |
