ZENIT® W600 Outdoor LED Wash Light

Item No.: CLZW600
Series: ZENIT® Series
Versions:
40 x 15 W RGBW LEDs with 21,000 lm total output for uniform and powerful colour mixing
18° beam and 35° field angles without diffuser
Optional SnapMag® filter frames for 25°, 45°, 100° or elliptical 60° x 10° beam angle selection and installation without tools or dismantling
Built-in 2.4 GHz W-DMX™ transceiver
Wireless master-and-slave function
Wireless DMX, RDM (via DMX and W-DMX™), standard DMX plus standalone modes with automated programs
IP65 rating for outdoor use
Temperature controlled fans for optimized operation and low noise
16-bit technology for high-resolution colours and dimming


Contents and categories

Display all

Contents and categories

Series

Search suggestions

Display all results
40 x 15 W RGBW LEDs with 21,000 lm total output for uniform and powerful colour mixing
18° beam and 35° field angles without diffuser
Optional SnapMag® filter frames for 25°, 45°, 100° or elliptical 60° x 10° beam angle selection and installation without tools or dismantling
Built-in 2.4 GHz W-DMX™ transceiver
Wireless master-and-slave function
Wireless DMX, RDM (via DMX and W-DMX™), standard DMX plus standalone modes with automated programs
IP65 rating for outdoor use
Temperature controlled fans for optimized operation and low noise
16-bit technology for high-resolution colours and dimming
Description

Equipped with a total of forty 15 W RGBW LEDs for a massive 21,000 lm output, the Cameo ZENIT® W600 is a powerful IP65 rated wash light for demanding outdoor applications. In addition to RDM and standard DMX capability it boasts a built-in 2.4 GHz W-DMX™ transceiver by Wireless Solution Sweden AB for convenient wireless control. The fixture also provides a rich variety of stunning automated programs for standalone or wireless master-and-slave operation.

For maximum versatility, the ZENIT® W600 sports Cameo's innovative SnapMag® technology. It allows you to add filter frames in less than a second without the need for tools or dismantling. Magnetic SnapMag® frames with precision light shaping diffusers providing a choice of 25°, 45°, 100° or elliptical 60° x 10° beam angles and a 4-way barn door are available as dedicated accessories.

Featuring advanced 16-bit technology for high-resolution colour mixing and dimming and an 18° beam spread, the ZENIT® W600 projects hugely intense, uniform washes. With colour temperature and individual LED colour correction, four selectable dimming curves and fully adjustable halogen lamp-like dimming response, the fixture is the perfect tool for highly professional lighting.

The ZENIT® W600's die cast aluminium housing integrates three temperature controlled fans that ensure optimized, low noise operation while a bright OLED display with four touch buttons permits easy, intuitive configuration. A security lock prevents unauthorized access to the luminaire's menu settings.

Specifications
DMX512
Environment-friendly
Protection class IP65
LED technology
Master & slave
RGB additive colour system plus white LEDs
Standalone mode
RDM

DMX512

Communication standard DMX512 was developed specially for lighting systems in 1986. Up to 32 DMX devices can be daisy-chained and controlled via a control source (e.g. a light mixer).

Environment-friendly

The high energy efficiency, the long service life of the LED lamps and the low level of heat dissipation make this device particularly environment-friendly.

Protection class IP65

The IP code of the protection class indicates how well the sensitive parts of the device are protected from foreign bodies and water entering. This device is fully protected from the penetration of dust and water jets.

LED technology

LEDs are ideal for use in lighting systems: They are bright and have a low level of heat dissipation, a long operating life and low energy consumption. Moreover, LED systems often weigh less than conventional lighting systems.

Master & slave

Master/slave operation allows identical DMX devices to be controlled by a DMX device of the same model and software standard. All the devices are connected by DMX cables in series. The master device is then set to run in standalone mode and the slave devices are set to run in slave mode.

RGB additive colour system plus white LEDs

Additional white LEDs create more contrast and clearer colour boundaries. What is more, they improve the creation of white and pastel colours.

Standalone mode

In standalone mode, the device functions are controlled via integrated programmes, so no light mixer or “master” controller is required.

RDM

This device has full RDM capability. The RDM protocol supplements the DMX protocol and enables bidirectional communication via a standard DMX network. It simplifies configuration, administration and monitoring of RDM devices connected to an RDM controller.

The W-DMX™ feature facilitates the wireless transmission of DMX control data.

This product is ETL certified.

General
Product type
LED Outdoor Wash Light
Type
ZENIT
Colour spectrum
RGBW
Number of LEDs
40
LED type
15 W
Average LED lifetime
50000 hrs.
Refresh rate
Adjustable: 800Hz, 1200Hz, 2000Hz, 3600Hz, 12000Hz, 25000 Hz
Dispersion
18° Beam, 35° Field (without diffusor) °
Lens
PE and tempered glass
DMX input
5-pin IP65
DMX output
5-pin IP65
DMX mode
10-channel, 15-channel, 2-channel, 3-channel, 4-channel, 8-1 Channel, 8-2 Channel
DMX Functions
Auto programs, colour macro, CTC (Colour Temperature Correction), Dimmer, Dimmer Curve, Dimmer Fine, Dimmer Response, RGBW, RGBW Fine, Strobe
Standalone modes
Auto programs, colour macro, Master / Slave mode, Settings, Static, system info, Tunable White, User Colours
Controls
Enter, Mode, Value Down, Value Up
Indicators
OLED Display
Power supply
100 V AC - 240 V AC, 50 - 60 Hz
Power consumption
565 W
power factor
0.99 PF (120V) / 0.96 PF (230V)
Power supply connector
IP65
Power supply connection
IP65
Housing material
Aluminium
Cabinet colour
Black
Protection class IP
IP65
Cooling
IP65 temperature-controlled fans
Luminous flux
21000 lm
Efficiency
37.2 lm/W
Operating Temperature
-15 - 45 °C
Accessories (included)
2 x omega mounting
Other features
ETL certified
Dimensions including Mounting Bracket
Width
463 mm
Length
291 mm
Height
161 mm
Weight
13 kg
