OPUS® X PROFILE

High-Power Profile Moving Head
Item No.: CLOXP
Series: OPUS
Versions:
High-power profile moving head with 33,000 lm / 72,000 lux (@ 5 m)
CMY colour blending and additional colour wheel with 6 dichroic filters
High-quality optics with 170-mm front lens and extremely wide zoom range of 6° to 48°
Angle and position of each diaphragm slider adjustable to complete closure
Rotatable animation wheel, rotating gobo wheel and static gobo wheel
Rotatable and indexable circular fivefold prism and linear sixfold prism
Variable frost filter for wash light effects and continuously adjustable iris
Smooth dimming with 16-bit resolution and 4 selectable curves
Battery-powered touchscreen display with rotary encoder
Flexible control via built-in W-DMX™ transceiver, DMX, RDM, Art-Net or sACN


Contents and categories

Display all

Contents and categories

Series

Search suggestions

Display all results
High-power profile moving head with 33,000 lm / 72,000 lux (@ 5 m)
CMY colour blending and additional colour wheel with 6 dichroic filters
High-quality optics with 170-mm front lens and extremely wide zoom range of 6° to 48°
Angle and position of each diaphragm slider adjustable to complete closure
Rotatable animation wheel, rotating gobo wheel and static gobo wheel
Rotatable and indexable circular fivefold prism and linear sixfold prism
Variable frost filter for wash light effects and continuously adjustable iris
Smooth dimming with 16-bit resolution and 4 selectable curves
Battery-powered touchscreen display with rotary encoder
Flexible control via built-in W-DMX™ transceiver, DMX, RDM, Art-Net or sACN
Description

Drawing only 750 W, achieve the same lighting performance that conventional devices require 1000 W for! This is possible thanks to the extremely efficient light engine of this incredibly modern high- power moving head from Cameo: the OPUS® X Profile.

The light engine efficiency of the Cameo OPUS X Profile Moving Head (item no.: CLOXP) can be seen throughout its design philosophy. This makes it possible to achieve 33,000 lm at a lighting power of 72,000 lux @ 5 metres. The complete setup with effects for use as spot and profile in this efficient and modern moving head is further augmented with the additional framing module. The high-quality optic with 170 mm front lens and a remarkably wide zoom range of 6° to 48° offers almost inexhaustible design possibilities. Be inspired by the combination of CMY colour blending and an additional colour wheel with 6 dichroic filters.

Cleverly coordinated and balanced functional features facilitate consistent projection without hotspots. The moving head is equipped with a +/- 45° rotatable, four-blade framing-shutter-system. Flickering in camera images is reliably prevented thanks to selectable PWM frequencies of up to 25 kHz. Light designers appreciate the rotatable animation wheel that doesn't limit their creativity. Fascinating lighting effects are created with the rotating gobo wheel in combination with six indexable, rotatable and exchangeable glass gobos, or optionally open. Alternatively, the static gobo wheel is available with seven exchangeable glass gobos or for open application.

With the circular fivefold prism, which is rotatable and indexable, and the linear sixfold prism, undreamed of possibilities for designing lighting effect sequences open up when used as a spot or profile. The angle and position of each diaphragm slider can be adjusted to achieve complete darkness. Combined with the variable frost filter for wash light effects and the continuously variable iris diaphragm, the creativity potential of this moving head is further multiplied. In standalone operation, control is either in static mode or on a master/slave basis and configured under independent power via the battery-powered touchscreen display with six touch keys. Greater flexibility is provided by the integrated W-DMX™ transceiver, DMX, RDM, Art-Net or sACN for controlling functions such as smooth dimming with 16-bit resolution and four selectable curves.

The attractive design of the spot and profile moving head proves itself in everyday use. Inside the robust metal and ABS plastic housing is a temperature-controlled fan working quietly to keep the housing cool. The separate power cable is one metre long and fitted with a Neutrik powerCON TRUE1 connector. The two included Omega mounting brackets allow for flexible installation of the spot/profile moving head.

Specifications
Cold white
DMX512
Environment-friendly
LED technology
Master & slave
Standalone mode
RDM
ARTNET compatible
4 framing shutter blades
Animation wheel
Circular prism
CMY
Colour wheel
Focus
(Gobo wheel)
Linear prism
Linear CTO
Iris
sACN compatible

Cold white

According to the colour temperature scale in Kelvin (K), “cold white” is a very bright, clear light in the colour temperature range between 5,000 and 10,000 K; it is slightly artificial in character and goes well with rich primary colours.

DMX512

Communication standard DMX512 was developed specially for lighting systems in 1986. Up to 32 DMX devices can be daisy-chained and controlled via a control source (e.g. a light mixer).

Environment-friendly

The high energy efficiency, the long service life of the LED lamps and the low level of heat dissipation make this device particularly environment-friendly.

LED technology

LEDs are ideal for use in lighting systems: They are bright and have a low level of heat dissipation, a long operating life and low energy consumption. Moreover, LED systems often weigh less than conventional lighting systems.

Master & slave

Master/slave operation allows identical DMX devices to be controlled by a DMX device of the same model and software standard. All the devices are connected by DMX cables in series. The master device is then set to run in standalone mode and the slave devices are set to run in slave mode.

Standalone mode

In standalone mode, the device functions are controlled via integrated programmes, so no light mixer or “master” controller is required.

RDM

This device has full RDM capability. The RDM protocol supplements the DMX protocol and enables bidirectional communication via a standard DMX network. It simplifies configuration, administration and monitoring of RDM devices connected to an RDM controller.

ARTNET compatible

The device is ArtNet compatible. ArtNet is a network protocol for transmitting DMX-512 or RDM data via an ethernet connection.

The PAN & TILT feature moves light emission along the X and Y axes.

The W-DMX™ feature facilitates the wireless transmission of DMX control data.

This product is ETL certified.

The high-frequency control of the LEDs while dimming ensures flicker-free operation, including for filming purposes.

4 framing shutter blades

Like wing limiters, but significantly more flexible, there are four diaphragm sliders here that enable the light beam to be shaped. Each diaphragm slider can be individually angled and inserted all the way for complete shading. The diaphragm slider system can be rotated by 45° in both directions for exact positioning.

Animation wheel

The rotating animation wheel provides three-dimensional effects and is especially effective when used in combination with gobos.

Circular prism

A circular prism multiplies the beam or the gobo projection, placing the result inside a circle.

CMY

This spotlight uses a white light source and subtractive CMY colour blending (cyan, magenta, yellow) for an extremely large palette of colours.

Colour wheel

Turning the colour wheel, which is fitted with various filters, enables very fast changes of colour.

Focus

The focus function serves to focus the light beam and the gobo projection at any distance.

(Gobo wheel)

Gobo wheels are fitted with static or rotating gobos made of metal or glass. Gobos are essentially templates that allow the projection of patterns, shapes and graphics.

Linear prism

A linear prism multiplies the beam or the gobo projection, placing the result inside a row.

Linear CTO

This spotlight has a continuously variable CTO correction function (colour temperature orange) which enables settings from cold white to tungsten and warm white.

Iris

The iris is a continuously variable opening for altering the diameter of the beam.

sACN compatible

This spotlight is compatible with the sACN protocol (streaming ACN) for transporting DMX data via a network.

General
Product type LED Moving Lights
Type Moving Head
Color temperature Cold White, 6100 K
LED PWM Frequency 650 Hz, 1530 Hz, 3600 Hz, 12000 Hz, 25000 Hz (adjustable)
Colour mixing function CMY, CTO
Color wheel Number of colors 6 + open and continuous positioning
LED type 750 W LED, white
Type Lamp 750 W LED
Dispersion 6 - 48 °
Effects 2 x Frost, 2 x Prism, Rotatable shutters
Number of gobos 13 + open (7 fixed + 6 rotating)
DMX input XLR 3-pin male, XLR 5-pin male
DMX output XLR 3-pin female, XLR 5-pin female
DMX mode 37-channel, 55-channel
DMX Functions Animation Wheel, Colour wheel, Colour wheel rotating, CTO, CTO Fine, Cyan, Cyan Fine, Dimmer, Dimmer Fine, Focus, Focus Fine, Frost 1/2, Gobo 1 Rotation, Gobo 1 Rotation Fine, Gobo 1 Shake, Gobo 2 Shake, Gobo Wheel 1, Gobo Wheel 2, Goborad 1 Rotation, Goborad 2 Rotation, Iris, LED Segment Dimmer, Magenta, Magenta Fine, Multifunctional Strobe, Pan/Tilt, Pan/Tilt fine, Pan/Tilt Macros, Pan/Tilt Speed, Prism 1/2, Prism Rotation, Shutter, Shutterblade Rotation, Sparkle FX, System settings, Yellow, Yellow Fine, Zoom, Zoom Fine
Standalone modes Master / Slave mode, Static
System settings Auto Focus, Auto Lock, Blackout functions, Colour/ Gobo wheel, Dimmer Curve, Display Illumination, Display Reverse, fan, Feedback, LED PWM Frequency, Motor Speed, Movement Blackout, pan, Pan Reverse, reset, Scroll / Snap, Signal Fail, Test, Tilt Reverse, User default values
Control Art-Net, DMX512, RDM enabled, sACN, W-DMX™ (Receiver)
Controls Back Button, Encoder wheel, Touch screen
Indicators Backlit colour LCD display, Battery supply for mains-independent system settings
Operating voltage 100 V AC - 240 V AC, 50 - 60 Hz
Power consumption 1200 W
Fuse T15AL / 250 V
Power connector Neutrik powerCON IN / OUT, Neutrik powerCON TRUE1 I/O
Housing material ABS, Metal
Cabinet colour Black
Cooling Silent, temperature controlled fan
Illuminance 72650 lx @ 5 m @ 6°
Luminous flux 33000 lm
Maximum Ambient Temperature 0 - 40 °C
Width 436 mm
Height 800 mm
Depth 312 mm
Relative Humidity < 80 %, not condensing, < 85 %, not condensing
Weight 42 kg
Accessories (included) 1 m Power cable with Neutrik powerCON TRUE1 plug, 2 x omega mounting
