ZIYA® 200 COB IP65 COB LED Zoom PAR

Item No.: CLZIYA200COB

Series: ZIYA®

Versions:

Zoom PAR with RGBALC COB LED for rich colours and uniform white light

Wide zoom range of 13°-35° (Field 27°-52°) for dynamic looks

CRI: 97 (3,200 K) / 96 (5,600 K)

Light output: 6,000 lm

Fresnel lens for homogeneous light distribution without hotspots

Variable colour temperature (CCT) from 2,400 K to 10,000 K and 15 colour presets

Various fan modes can be selected

Robust IP65 housing for outdoor and touring applications

Patented SPIN16® technology for quick and flexible installation thanks to the 16 mm TV spigot integrated into the bracket

Optional accessories: barndoor & flight case

Buy

Search now

Contents and categories

Display all

Contents and categories

Series

Search suggestions

Display all results

Zoom PAR with RGBALC COB LED for rich colours and uniform white light

Wide zoom range of 13°-35° (Field 27°-52°) for dynamic looks

CRI: 97 (3,200 K) / 96 (5,600 K)

Light output: 6,000 lm

Fresnel lens for homogeneous light distribution without hotspots

Variable colour temperature (CCT) from 2,400 K to 10,000 K and 15 colour presets

Various fan modes can be selected

Robust IP65 housing for outdoor and touring applications

Patented SPIN16® technology for quick and flexible installation thanks to the 16 mm TV spigot integrated into the bracket

Optional accessories: barndoor & flight case

Description

The ZIYA® 200 COB is a compact LED zoom PAR with RGBALC COB LED technology and IP65 certification. It provides uniform illumination, rich colours and natural white tones – ideal for theatres, live events and exhibition lighting. Its flexible zoom range of 13° to 35° (field 27°-52°) and Fresnel optics ensure consistent lighting without hotspots and smooth transitions.

The RGBALC colour mixing system offers precise control over colour and white light, while the vibration-free silent zoom and quiet fan modes enable use in noise-sensitive environments. The housing is bevelled at the rear so that cables can be conveniently connected even when installed. Together with the patented SPIN16® system and the robust IP65 design, the ZIYA® 200 COB ensures reliable operation in any type of installation.

Specifications

Photometric values

Illuminant type

RGBALC LED

Illuminant power

200 W

LED data

1 x 200 W RGBALC LED

Luminous flux

6,000 lm

Front lens diameter

139 mm

Beam/Field angle

Beam: 13° / Field: 50°

Zoom range

13 - 50 °

LED PWM frequency

1,530 Hz, 3,600 Hz, 12 kHz, 18.9 kHz, 25 kHz

Dimmer resolution

16 Bit

Dimmer curves

Linear, Exponential, Logarithmic, S curve, Tungsten

Colours

Colour mix functions

RGB

LED colours

Red, Green, Blue, Amber, Lime, Cyan

Colour control

Analog modulation, Colour film (GEL), HSI, Direct (single control), CTC with tint, xy (color triangle)

Correlated colour temperature (CCT)

2,400 - 10,000 K

Colour rendering index (CRI)

> 97

Effects

Strobe

0 - 20 Hz

Framing blades

Control

Controller protocols

DMX512, RDM, W-DMX™ (Receiver)

Number of DMX control modes

Stand alone operating modes

Autorun, Master/slave, Static, Stand-alone

Data in connector

XLR 5-pole male

Data out connector

XLR 5-pole female

Mains operation

Operation voltage

100 V AC - 240 V AC / 50 - 60 Hz

Rated power

200 W

Mains connector

Mains plug device outdoor male & TRUE1®

Power out connector

Mains plug device outdoor female & TRUE1®

Housing

Chassis material

Die-cast aluminium

Colour

Black

Cooling

Cooling system

Temperature controlled fan cooling

Environmental

Protection class

IP65

Risk group

Ambient temperature

-15 - 45 °C

Maximum air humidity (non-condensing)

100 %

Dimensions & weight

Width

213 mm

Height

202 mm

Depth

312 mm

Weight

7.9 kg

Other properties

Included Accessories

Mains cable
