ZENIT® B60 B LSD Battery-Powered W-DMX™ IP65 PAR Light black

Item No.: CLZB60BLSD
Series: ZENIT® Series
Versions:
4 x 15 W RGBW Cree LEDs with 1,900 lm total output for uniform colour mixing
Long-life super capacity lithium-ion battery for reliable operation
Battery management system prevents overcharging and exhaustive discharge
Built-in 2.4 GHz W-DMX™ receiver
Wireless DMX, standard DMX, RDM and IR control or via the four touch buttons display
Includes two light shaping diffusers for flexible 11°, 25° or 40° beam spread options, elliptical diffuser 60° x 10° available as accessory
16-bit technology for high-resolution colours and dimming
OLED display with four touch buttons for easy configuration
Security lock against unauthorized menu access


Contents and categories

Display all

Contents and categories

Series

Search suggestions

Display all results
4 x 15 W RGBW Cree LEDs with 1,900 lm total output for uniform colour mixing
Long-life super capacity lithium-ion battery for reliable operation
Battery management system prevents overcharging and exhaustive discharge
Built-in 2.4 GHz W-DMX™ receiver
Wireless DMX, standard DMX, RDM and IR control or via the four touch buttons display
Includes two light shaping diffusers for flexible 11°, 25° or 40° beam spread options, elliptical diffuser 60° x 10° available as accessory
16-bit technology for high-resolution colours and dimming
OLED display with four touch buttons for easy configuration
Security lock against unauthorized menu access
Description

With battery operation, built-in wireless DMX and IP65 rating, the Cameo ZENIT® B60 is ready for demanding indoor and outdoor lighting applications. The highly professional PAR light sports four 15 W RGBW Cree LEDs with a 50,000 hour lifetime and powerful 1,900 lm output for brilliant, uniform colours with a precise 11° beam spread. For extra versatility it comes with two specially designed light shaping diffusers offering a choice of 25° or 40° beam angles while maintaining output.

In addition to seven modes of DMX, RDM and IR remote or manual control via the fixture’s display the ZENIT® B60 incorporates a 2.4 GHz W-DMX™ receiver. Developed by Wireless Solution Sweden AB, W-DMX™ has become the unofficial standard for professional wireless lighting control. The luminaire’s super capacity lithium-ion battery is made providing reliable performance up to 24 hours from a single charge with adjustable runtime in one hour increments. An intelligent control automatically calculates brightness, and the PAR light’s battery management system prevents overcharging and exhaustive discharge for extended battery life.

Sporting a 3,600 Hz refresh rate for flicker-free performance and highly efficient convection cooling for noiseless operation, the ZENIT® B60 is perfect for motion picture and TV applications. It utilises 16-bit technology for smooth high-resolution colour mixing and dimming and includes individual LED colour temperature correction plus a selection of dimming curves with adjustable response. The aluminium housing features a bright OLED display with four touch buttons for easy configuration while a security lock prevents unauthorized menu access.

Specifications
DMX512
Environment-friendly
Protection class IP65
Infrared remote control
LED technology
Master & slave
RGB additive colour system plus white LEDs
Standalone mode
Strobe

DMX512

Communication standard DMX512 was developed specially for lighting systems in 1986. Up to 32 DMX devices can be daisy-chained and controlled via a control source (e.g. a light mixer).

Environment-friendly

The high energy efficiency, the long service life of the LED lamps and the low level of heat dissipation make this device particularly environment-friendly.

Protection class IP65

The IP code of the protection class indicates how well the sensitive parts of the device are protected from foreign bodies and water entering. This device is fully protected from the penetration of dust and water jets.

Infrared remote control

The device is fitted with an infrared sensor and can be controlled wirelessly using the IR remote control unit included.

LED technology

LEDs are ideal for use in lighting systems: They are bright and have a low level of heat dissipation, a long operating life and low energy consumption. Moreover, LED systems often weigh less than conventional lighting systems.

Master & slave

Master/slave operation allows identical DMX devices to be controlled by a DMX device of the same model and software standard. All the devices are connected by DMX cables in series. The master device is then set to run in standalone mode and the slave devices are set to run in slave mode.

RGB additive colour system plus white LEDs

Additional white LEDs create more contrast and clearer colour boundaries. What is more, they improve the creation of white and pastel colours.

Standalone mode

In standalone mode, the device functions are controlled via integrated programmes, so no light mixer or “master” controller is required.

Strobe

Strobes emit fast flash sequences, which makes movements appear “frozen” and creates a kind of slow-motion effect.

The W-DMX™ feature facilitates the wireless transmission of DMX control data.

General
Product type
LED PAR Lighting
Type
Outdoor
Colour spectrum
RGBW
Number of LEDs
4
LED type
15 W
Refresh rate
3600 Hz
Dispersion
Without diffusor - (Beam) 11° / (Field) 18 °
DMX input
5-pin IP65
DMX output
5-pin IP65
DMX mode
10-channel, 15-channel, 2-channel, 3-channel, 4-channel, 8-1 Channel, 8-2 Channel
DMX Functions
colour change, colour fade, colour jump, colour macro, CTC (Colour Temperature Correction), Dimmer, Dimmer Curve, Dimmer Fine, Dimmer Response, reset, RGBW, RGBW Fine, Strobe
Standalone modes
Auto programs, colour fade, colour jump, colour macro, Dimmer Curve, Dimmer Response, Display Lock, Master / Slave mode, static colour, Strobe, White Balance adjustable
Controls
Enter, Mode, Value Down, Value Up
Indicators
OLED Display
Operating voltage
100 V AC - 240 V AC, 50 - 60 Hz
Power consumption
100 W
Power supply connector
IP65
Power supply connection
IP65
Housing material
Die-cast aluminium
Cabinet colour
Black
Protection class IP
IP65
Battery capacity
217 Wh
Battery capacity
20.1 Ah
Battery operation time at maximum load
up to 24 hours
Charging time
4h
Cooling
Convection
Illuminance
40000lx @ 1m
Luminous flux
1900 lm
Efficiency
32 lm/W
Operating Temperature
0 - 40 °C
Dimensions without mounting bracket
Width
187 mm
Height
187 mm
Length
164 mm
Weight
5,4 kg
Accessories (included)
Design Bracket
